Read articleSN74LS86ANLX - LX Logic IC, DIP-14
Regular price
$0.10
After you place an order, our sales team will send written confirmation of the final price, shipping charges, and estimated delivery lead time. Import duties, taxes, brokerage fees, and other destination charges are the customer's responsibility. When needed, we can assist with available product information and customs documents for import declaration; final customs clearance and payment remain the customer's responsibility.
Couldn't load pickup availability
Integrated Circuit
SN74LS86ANLX
SN74LS86AN(LX) DIP-14
In Stock
DIP14
Active
Pricing & Availability
Price$0.0777 USD
AvailabilityIn Stock
ManufacturerLX(coreµ)
PackageDIP14
AvailabilityIn Stock
Pack1000
Basic Information
| Manufacturer | LX(coreµ) |
|---|---|
| Manufacturer Part Number | SN74LS86ANLX |
| Description | SN74LS86AN(LX) DIP-14 |
| IC Category | |
| Package | DIP14 |
| Packaging | - |
| Availability | In Stock |
| Standard Pack Quantity | 1000 |
| Available Stock | 998 |
| Lifecycle Status | Active |
Key Specifications
| Number of Channels | 4 |
|---|---|
| Operating Voltage | 2V ~ 6V |
| Quiescent Current (Iq) | 2uA |
| current(IOL) | 5.2mA |
| current(IOH) | 5.2mA |
| input high (VIH) | 1.5V ~ 4.2V |
| input low (VIL) | 500mV ~ 1.8V |
Technical Attributes
| inputoutputhigh (VOH) | 5.9V; 1.9V; 4.4V |
|---|---|
| inputoutputlow (VOL) | 100mV; 260mV; 260mV |
| Propagation Delay (tpd) | 20ns@6V, 50pF |
| Operating Temperature | -40°C ~ +125°C |
| Input Channel | 2 |
| Features | input |
Documents & Engineering Resources
Inventory and pricing are updated regularly. Technical data is provided for engineering reference.
Datasheet PDF
