Read articleSIG5532B-ITSP20-RL - Signal Micro Data Converter, TSSOP-20
Regular price
$8.48
Volume Discounts
| Quantity | Unit Price |
|---|---|
| 1+ | $8.48 |
| 10+ | $7.35 |
| 30+ | $6.67 |
| 100+ | $6.09 |
After you place an order, our sales team will send written confirmation of the final price, shipping charges, and estimated delivery lead time. Import duties, taxes, brokerage fees, and other destination charges are the customer's responsibility. When needed, we can assist with available product information and customs documents for import declaration; final customs clearance and payment remain the customer's responsibility.
Couldn't load pickup availability
Integrated Circuit
SIG5532B-ITSP20-RL
SPI 4.75V~5.25V TSSOP-20 Analog to Digital Converters (ADC) RoHS
In Stock
TSSOP-20
normal
Unit Price$8.476
In Stock
ManufacturerSignal Micro
PackageTSSOP-20
Stock1157
PackTape & Reel (TR)
Basic Information
| Manufacturer | Signal Micro |
|---|---|
| Manufacturer Part Number | SIG5532B-ITSP20-RL |
| Description | SPI 4.75V~5.25V TSSOP-20 Analog to Digital Converters (ADC) RoHS |
| IC Category | Analog to Digital Converters (ADC) |
| Package | TSSOP-20 |
| Packaging | Tape & Reel (TR) |
| Standard Pack Quantity | 4500 |
| Available Stock | 1157 |
| Availability | In Stock |
| Lifecycle Status | normal |
Key Specifications
| Operating Temperature | -40 C~+125 C |
|---|---|
| Interface | SPI |
| Quiescent Current (Iq) | 5.6mA |
| Voltage - Supply | 4.75V~5.25V |
| Number of Channels | 1 |
| Integral non-linearity | - |
| Voltage Reference | Built-in; External |
Technical Attributes
| Clock/Oscillator | Built-in; External |
|---|---|
| Clock Frequency | 4.9152MHz; 1MHz~5MHz |
| Features | Bipolar power supply; Integrated modulator; Built-in digital filter; Power-on reset |
| Resolution(Bits) | 32; 1.875Hz |
| S/N Ratio | - |
| ADC architecture | Sigma-Delta |
| Programmable Gain | Support |
Documents & Engineering Resources
Inventory, lead time, and pricing are updated regularly. Technical data is provided for engineering reference.
Datasheet PDF
