TPS563200DDCR - Texas Instruments DC-DC Converter, TSOT-23-6
Regular price
$1.02
After you place an order, our sales team will send written confirmation of the final price, shipping charges, and estimated delivery lead time. Import duties, taxes, brokerage fees, and other destination charges are the customer's responsibility. When needed, we can assist with available product information and customs documents for import declaration; final customs clearance and payment remain the customer's responsibility.
Couldn't load pickup availability
Integrated Circuit
TPS563200DDCR
Buck Switching Regulator IC Adjustable 0.76V~7V 1 Output 3A TSOT-23-6
In Stock
TSOT-23-6
normal
Unit Price$1.2305
In Stock
ManufacturerTI
PackageTSOT-23-6
Stock4866
PackTape & Reel (TR)
Basic Information
| Manufacturer | TI |
|---|---|
| Manufacturer Part Number | TPS563200DDCR |
| Description | Buck Switching Regulator IC Adjustable 0.76V~7V 1 Output 3A TSOT-23-6 |
| IC Category | Voltage Regulators - DC DC Switching Regulators |
| Package | TSOT-23-6 |
| Packaging | Tape & Reel (TR) |
| Standard Pack Quantity | 3000 |
| Available Stock | 4866 |
| Availability | In Stock |
| Lifecycle Status | normal |
Key Specifications
| Operating Temperature | -40℃~+85℃@(TA) |
|---|---|
| Frequency - Switching | 650kHz |
| Function | Step-down type |
| Number of Outputs | 1 |
| Features | Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Overcurrent Protection |
| Output Type | Adjustable |
| Topology | Buck |
Technical Attributes
| Operating Voltage | 4.5V~17V |
|---|---|
| Switch tube (built-in/external) | Built-in |
| Output Voltage | 760mV~7V |
| Output Current | 3A |
| Quiescent Current | 190uA |
Documents & Engineering Resources
Inventory, lead time, and pricing are updated regularly. Technical data is provided for engineering reference.
Datasheet PDF
